PRINTING& DYEING

Precise pH control provides a stable guarantee for product quality, while real time monitoring of auxiliaries, water, and steam flow significantly reduces operating costs and minimizes the environmental impact of production. Fullkon has accumulated extensive application experience in the textile dyeing and finishing industry. Leveraging its strengths in process automation and digital platforms, Fullkon provides solutions for energy conservation, consumption reduction, and production optimization, helping enterprises achieve their dual carbon goals.

Dye pH Monitoring

Measured Medium: Dye Dispersant

Recommended Configuration: pH Transmitter + pH Electrode

Selection Recommendations:

① Solution temperature up to 90° C, pH > 10；

② pH electrode must withstand high-temperature and strong alkaline environments;

③ pH electrode is a consumable,regular replacement is recommended.

Chemical Tank Level Detection

Measured Medium: Textile auxiliaries / Dyes / Washing agents

Recommended Configuration: Pressure Transmitter

Selection Recommendations:

① Range 10kPa or 20kPa, output signal 4~20mA；

② Internal encapsulation to resist high humidity environments;

③ If in direct contact with liquid and the medium is alkaline, use 316L material for the threaded connection.

Airflow Dyeing Machine Flow Monitoring (Water, Steam)

Measured Medium: Water, Steam

Recommended Configuration:Electromagnetic Flow Meter；Vortex Flow Meter

Selection Recommendations:

① For low-temperature dyeing tank inlet water, use an integrated electromagnetic flow meter；

② For high-temperature outlet water, use a split-type flow meter；

③ For steam supply to textile dyeing equipment, use a vortex flow meter；

④ In high-temperature and high-humidity environments, ensure proper protection and grounding of instruments.
